Bowsers

In the Bowsers step, you can define the types of fuel bowsers to be modeled in your simulation. This step focuses on specifying 'bowser types' rather than individual on-site bowser instances. Later in the software, the site specific instances are created where they are mapped to a defined bowser type.

An example of a two Bowser types.

Bowsers are managed using the toolbar located at the top of the page. More information on the functions within the toolbar can be found in the Common User Controls page. Each bowser type instance must have the following properties specified:

Input	Description
Name	Specifies the name of the bowser type.
Flow Rate (l/h)	Defines the maximum flow rate, in the specified units, the bowser can supply.
Setup Time (s)	Time required to connect the bowser to the vehicle.
Tear Down Time (s)	Time required to disconnect the bowser from the vehicle.
